GENERAL CONSIDERATIONS
+ Biologic Behavior
- HSA is a highly metastatic tumor with microscopic or macroscopic metastatic disease at diagnosis
- HSA arises from vascular endothelial cells
- HSA is the most common splenic tumor in dogs and accounts for 24%-50% dogs with splenic masses
- Splenic hemangioma and hematoma occur in 3%-34% dogs with splenic masses
- Other primary HSA sites include right atrium, liver, integument, urinary bladder, prostate, kidney, muscle, bone, CNS, and oral cavity
- Median age 9.0-10.5 years
- Sex predisposition: males
- Breed predisposition: GSD, Golden Retriever, Labrador Retriever, and Schnauzer
- Cause is unknown although linked with exposure to thorium dioxide, arsenical or vinyl chloride compounds, ultraviolet light, and local radiation therapy in humans
- 25% of dogs with splenic HSA have concurrent right atrial HSA
- HSA is highly metastatic: > 50% metastatic rate for splenic HSA
- Lungs are the most common metastatic site (64%-67%), followed by spleen (36%-60%), kidneys (55%), liver (41%-55%), brain (20%), intestines (20%), adrenal glands (20%), skeletal muscle (20%), visceral lymph nodes (15%), skin and subcutaneous tissue (15%), left ventricle (10%), and mesentery and omentum (10%)
- Tumor rupture or erosion through blood vessels is common and results in seeding of peritoneum or omentum with tumor cells
- Splenic tumors other than HSA include LSA (4%), various sarcomas (i.e., undifferentiated sarcoma, FSA, leiomyosarcoma, mesenchymoma, myxosarcoma, histiocytic sarcoma, OSA, and liposarcoma), and metastatic carcinomas
Diagnosis
+ General Considerations
- Splenic HSA and hemangioma have similar ultrasonographic and gross appearance and are difficult to differentiate
- HSA is significantly more likely to have increased VEGF levels
- Hemoabdomen is more common in dogs with HSA (76.4%) compared to hemangioma (29.6%)
- Neoplastic disease accounts for 80% of non-traumatic hemoabdomen cases in dogs and HSA for 88% of these cases
- Neoplastic effusion can be differentiated from non-neoplastic as neoplastic effusions have:
- Significantly lower glucose concentrations (72.6 mg/dL v 110.0 mg/dL)
- Significantly higher lactate concentrations (3.81 mmol/L v 1.68 mmol/L)
+ Laboratory Findings
- Hematology: anemia and morphological changes to red blood cells such as nucleated erythrocytes, polychromasia, poikilocytes, anisocytes, shistocytes, and reticulocytes
- Morphologic changes due to iron loss, altered hepatic lipoprotein metabolism, microangiopathic disease, or DIC and sluggish flow through abnormal vascular channels resulting in increased membrane fragility
- Neutrophilic leukocytosis is common due to either stress or tumor rupture and necrosis
- Thrombocytopenia due to DIC, but may form part of Kasabach-Merritt syndrome
- Kasabach-Merritt syndrome is characterized by an enlarging vascular tumor, thrombocytopenia, anemia, prolonged PT and APTT, decreased FDP, and increased fibrin split products
- Thrombocytopenia (75%-90%), fragmented red blood cells (80%), and DIC (50%) are common findings
- Anemia and DIC associated with blood loss is common in cats with visceral HSA
+ Survey Radiographs
- 2 metastatic patterns in dogs with HSA:
- Widely disseminated nodular pattern (common)
- Diffuse interstitial pattern (uncommon)
- False-negative results are high: 22% from splenic HSA and > 50% for right atrial HSA
+ Ultrasonography
- Abdominal ultrasonography is a highly accurate and sensitive tool for splenic evaluation
- Primary HSA: mixed pattern of anechoic and hyperechoic regions
- Metastatic HSA: diffusely anechoic or hypoechoic appearance
- Ultrasound-guided FNA or needle-core biopsy contraindicated due to risk of seeding and low diagnostic yield
+ Electrocardiography
Ventricular arrhythmias are commonly associated with HSA due to hypoxia, anemia, or hypovolemia
TREATMENT
+ Surgical Management
- Total splenectomy recommended
- Total splenectomy is considered a palliative procedure to reduce the risk of hemorrhage
+ Chemotherapy
- Doxorubicin 30 mg/m2 q 2-3 weeks for 5 doses
- ± cyclophosphamide 100-150 mg/m2
- Complications: neutropenia (common), severe gastroenteritis, cardiotoxicity, and sepsis
+ Immunotherapy
- Immunotherapy aims at altering host-tumor response
- Mixed bacterial vaccination and liposome-encapsulated muramyl tripeptide phosphatidylethanolamine (L-MTPE) have been investigated with mixed results
+ Other Treatments
Angiogenesis inhibitors and gene therapy
Complications
+ Hemorrhage
- Hemorrhage is caused by tumor rupture, manipulation of the spleen or liver, and inadequate ligation
- Treatment: intravenous fluids and fresh whole blood (preferred as thrombocytopenia common in HSA)
- Autotransfusion contraindicated due to neoplastic cells and low clotting factors and platelets
+ Coagulopathy
- Fragmentation anemia and thrombocytopenia are common ± DIC
- Treatment: intravenous fluids (to maintain circulating volume) and fresh whole blood transfusions
+ Cardiac Arrhythmias
- Ventricular extrasystole and ventricular tachycardia
- Possible causes of cardiac arrhythmias include release of emboli during splenic manipulation, transient ischemic episodes, and release of toxic factors from abdominal viscera into the splanchnic circulation
- Treatment: correct underlying cause, correct acid-base and electrolyte abnormalities, intravenous fluids ± anti-arrhythmic drugs (lidocaine)
- Continuous ECG monitoring is recommended for 12-36 hours post-splenectomy
+ Prognosis
- Poor prognosis
- MST 19-86 days with surgery alone, with 12-month survival rate 6.25%
- MST 172-202 days with surgery and chemotherapy with 12-month survival rate up to 20%
- MST 257-273 days for stage I HSA
- MST 156-210 days for stage II HSA
- MST 107-136 days for stage III HSA
- Prognostic factors include clinical stage and addition of immunotherapy:
- Stage III disease (i.e., metastasis) significantly decreases MST (60-107 days v 172-273 days) and 12-month survival rate (0% v 20%)
- L-MTPE combined with surgery and chemotherapy significantly improves MST compared to surgery and chemotherapy only (277 days v 143 days)
SPLENIC HEMANGIOSARCOMA
T0 | No evidence of neoplasia |
T1 | Tumor less than 5 cm in diameter and confined to primary site - Primary Tumor |
T2 | Tumor ≥ 5 cm in diameter, ruptured, or invading subcutaneous tissue |
T3 | Tumor invading adjacent structures including muscle |
M0 | No evidence of metastasis |
M1 | Evidence of distant metastasis with site specified - Metastasis |
N0 | No evidence of regional lymph node involvement |
N1 | Regional lymph node involvement - Node |
N2 | Distant lymph node involvement |
Clinical Stage
I | II | III | T | T1 | T0-1 | T1-2 | T2-3 | N | N0 | N0-1 | N0-2 | M | M0 | M0 | M2 |
